| ANTENNA COAXIAL CABLE
/ (1) RG-SERIES (UL1354,UL1365,UL1478,UL1792) |
COAXIAL CABLE
RG-TYPE CABLE (UL1354, 1365, 1478, 1792) STANDARD SIZE/SPECIFICATION
TYPE DESIGNATION:
APPLICATIONS:
- FOR INTERNAL WIRING TV, RADIO, RECEIVERS VTR, TAPE RECORDER, LOCAL AREA NETWORK, ANTENNA, SATELLITE, AND OTHER ELECTRONIC EQUIPMENT.
|
DESCRIPTION:
◆ UL 1354
- STRANDED, OR SOLID, TINNED OR BARE, COPPER OR COPPER ALLOY CONDUCTOR.
- RATED TEMP: 60 OR 80℃, RATED VOLTAGE: 30 VOLTS.
- LOW LOSSES AND LOW PROPAGATION DELAYS.
◆ UL 1365
- STRANDED, OR SOLID, TINNED OR BARE, COPPER OR COPPER ALLOY CONDUCTOR.
- RATED TEMP: 60℃, RATED VOLTAGE: 300 VOLTS.
◆ UL 1478
- STRANDED, OR SOLID, TINNED OR BARE, COPPER OR COPPER ALLOY CONDUCTOR.
- RATED TEMP: 60℃, RATED VOLTAGE: 300 VOLTS.
- PASSES UL VW-1 VERTICAL FLAME TEST.
◆ UL 1792
- STRANDED, OR SOLID, TINNED OR BARE, COPPER OR COPPER ALLOY CONDUCTOR.
- RATED TEMP: 80℃, RATED VOLTAGE: 30 VOLTS.
- LOW LOSSES AND LOW PROPAGATION DELAYS.
|
| TYPE |
CONDUCTOR |
INSULATION |
BRAID SHIELD |
JACKET |
NOM.
IMPED.
OHM |
NOM.
CAPA.
PF/M |
ATTENUATION
100MHZ
DB/KM |
| NO./MM |
MTRL |
MM |
MTRL |
NO./MM |
NO./MM |
MTRL |
MM |
MTRL |
| RG-6/U |
1/1.02 |
C |
4.57 |
FPE |
AF |
95% |
T |
6.9 |
PVC |
75 |
55 |
94 |
| RG-8/U |
7/0.9 |
C |
7.24 |
FPE |
95% |
- |
C |
10.3 |
PVC |
52 |
85 |
64 |
| RG-8/U |
7/0.724 |
C |
7.24 |
PE |
95% |
- |
C |
10.3 |
PVC |
52 |
97 |
70 |
| RG-8A/U |
7/0.724 |
C |
7.24 |
PE |
95% |
- |
C |
10.3 |
NC-PVC |
52 |
97 |
70 |
| RG-8/X |
19/0.287 |
C |
3.94 |
FPE |
95% |
- |
C |
6.15 |
PVC |
52 |
85 |
121 |
| RG-11/U |
1/1.63 |
C |
7.24 |
FPE |
DF |
75% |
T |
10.3 |
PVC |
75 |
57 |
49 |
| RG-11/U |
7/0.404 |
T |
7.24 |
PE |
95% |
- |
T |
10.3 |
PVC |
75 |
67 |
72 |
| RG-14/U |
1/2.591 |
C |
9.4 |
PE |
97% |
97% |
CC |
13.8 |
PVC |
52 |
97 |
50 |
| RG-55A/U |
1/0.889 |
S |
2.9 |
PE |
97% |
97% |
SS |
5.4 |
NC-PVC |
50 |
97 |
120 |
| TWINAXIAL |
7/0.32X2 |
T,C |
5.99 |
PE |
95% |
- |
T |
8.4 |
PVC |
100 |
51 |
136 |
| RG-58/U |
1/0.8 |
C |
2.9 |
PE |
95% |
- |
T |
5.0 |
PVC |
50 |
94 |
140 |
| RG-58A/U |
19/0.203 |
T |
2.9 |
FPE |
AF |
97% |
T |
5.03 |
PVC |
50 |
86 |
131 |
| RG-58A/U |
19/0.18 |
T |
2.95 |
PE |
95% |
- |
T |
4.95 |
PVC |
50 |
102 |
160 |
| RG-58C/U |
19/0.18 |
T |
2.95 |
PE |
95% |
- |
T |
4.95 |
NC-PVC |
50 |
102 |
160 |
| THIN ETHERNET |
19/0.203 |
T |
2.59 |
FPE |
DF |
97% |
T |
4.62 |
NC-PVC |
50 |
83 |
131 |
| RG-59/U |
7/0.254 |
C |
3.71 |
FPE |
95% |
- |
C |
6.15 |
PVC |
75 |
57 |
98 |
| RG-59/U |
1/0.81 |
C |
3.71 |
FPE |
95% |
95% |
C |
6.15 |
PVC |
75 |
57 |
98 |
| RG-59/U DUAL |
1/0.643 |
CW |
3.71 |
PE |
95% |
- |
C |
6.15X12.4 |
PVC |
75 |
67 |
112 |
| RG-59/U |
1/0.643 |
CW |
3.71 |
PE |
95% |
- |
C |
6.15 |
PVC |
73 |
69 |
120 |
| RG-59A/U |
17/0.16 |
C |
3.71 |
PE |
95% |
- |
C |
6.15 |
NC-PVC |
73 |
69 |
120 |
| RG-59B/U |
1/0.584 |
CW |
3.71 |
PE |
95% |
- |
C |
6.15 |
NC-PVC |
75 |
67 |
120 |
| RG-62/U |
1/0.643 |
CW |
3.71 |
SSPE |
95% |
- |
C |
6.15 |
PVC |
93 |
44 |
83 |
| RG-62A/U |
1/0.643 |
CW |
3.71 |
SSPE |
95% |
- |
C |
6.15 |
NC-PVC |
93 |
44 |
83 |
| RG-62B/U |
7/0.203 |
CW |
3.71 |
SSPE |
95% |
- |
C |
6.15 |
NC-PVC |
93 |
44 |
100 |
| RG-71B/U |
1/0.643 |
CW |
3.71 |
SSPE |
95% |
95% |
TT |
6.22 |
PE |
93 |
44 |
84 |
| RG-174/U |
7/0.16 |
CW |
1.52 |
PE |
95% |
- |
T |
2.8 |
PVC |
50 |
100 |
260 |
| RG-174A/U |
7/0.16 |
CW |
1.52 |
PE |
95% |
- |
T |
2.8 |
NC-PVC |
50 |
100 |
260 |
| RG-212/U |
1/1.412 |
S |
4.7 |
PE |
97% |
97% |
SS |
8.4 |
NC-PVC |
50 |
98 |
87 |
| RG-213/U |
7/0.752 |
C |
7.24 |
PE |
95% |
- |
C |
10.3 |
NC-PVC |
50 |
98 |
70 |
| RG-214/U |
7/0.752 |
S |
7.24 |
PE |
97% |
97% |
SS |
10.8 |
NC-PVC |
50 |
98 |
67 |
| RG-216/U |
7/0.404 |
T |
7.24 |
PE |
97% |
97% |
CC |
10.8 |
PVC |
75 |
67 |
72 |
| RG-223/U |
1/0.889 |
S |
2.9 |
PE |
97% |
97% |
SS |
5.3 |
NC-PVC |
50 |
98 |
120 |
|
|
|
|
